Door Access Reimagined

Seamless network integration

Easily integrate your Access devices into a new or existing UniFi system.
Note: The Access Reader Pro (UA Pro) must be installed either indoors or under a roof eave outdoors.

Access Products

Access Starter Kit

Datasheet

A comprehensive single-door access control system.
Includes:

    • (1) Access Hub
    • (1) Access Reader Pro*
    • (1) Access Reader Lite*
    • (20) UniFi Access Cards

Access Hub

Datasheet

A single-door mechanism that provides complete entry control via connected Access Readers.
Features:

    • (3) PoE ports to connect Access Readers or Protect cameras
    • (2) Lock relays to support 12V-powered and dry options
    • (2) AUX relays to connect an external siren and automatic door opener
    • (4) Inputs for motion sensors, push buttons, emergency alarms, and a door position sensor
    • Powered with PoE++

Access Reader Pro

Datasheet

A premium door access scanner with built-in NFC reader and intercom.

This device can be installed indoors or under a roof overhang outside.

Features:

    • (1) PoE input powered by an Access Hub
    • (1) High-resolution touchscreen with a built-in camera
    • Security chip that supports advanced NFC encryption
    • Mobile unlocking with the Access or UI mobile apps

Access Reader Lite

Datasheet

A convenient door access scanner supporting NFC reader and handwave door unlocking.

This device can be installed indoors or under a roof overhang outside.

Features:

    • (1) PoE input powered by an Access Hub
    • Security chip that supports advanced NFC encryption
    • Mobile unlocking with the Access or UI mobile apps

Access Card

Datasheet

A pack of (20) highly secure NFC cards used with our Access Readers to unlock doors.

Access Rescue KeySwitch

Datasheet

A key switch that allows you to manually override a malfunctioning fail-safe or secure* lock system.

Each pack includes:

    • (1) UA Rescue key switch
    • (2) Keys

Enhance your existing door security with Access devices

UniFi Access works with most electric bolts, magnetic locks, and electric strikes.

Door Access FAQ

Your Title Goes Here

Your content goes here. Edit or remove this text inline or in the module Content settings. You can also style every aspect of this content in the module Design settings and even apply custom CSS to this text in the module Advanced settings.

What do I need to use UniFi Access?
  • A UniFi OS Console, such as a Dream Machine Pro or Cloud Key Gen2 Plus, running the Access application.
  • A PoE switch to connect your Access device(s). We recommend a UniFi PoE++ switch.
  • A UA Hub
  • A UA Pro or UA Lite reader to control door access in one direction. Two readers are required to control two-way access.
Can a single UA Hub manage multiple doors?
A UA Hub can only manage one door at a time. Multiple hubs are required for multiple doors.
How many UA Hubs can be managed by the Access application?
An Access application hosted on a UDM Pro can support up to 100 UA Hubs.
Do I need to purchase specific maglocks to use UniFi Access?
The UA Hub works with most maglocks that support 12V and have a maximum current that doesn’t exceed 1A. If your lock differs, the power lock relay will be used. You will not need an external power supply.

If your maglock is 24V, you can still connect the UA Hub’s lock dry relay to an external power supply. If you don’t want to power your maglock with an external adapter, though, you can use the UA Hub’s power lock relay.

Does UniFi Access have emergency functionality for fires, lockdowns, and evacuations?
Yes, our devices can be manually engaged and bypassed depending on the situation to ensure optimal safety.
Will UniFi Access remain operational during a power outage?
Yes, the UA Hub can operate offline without UniFi Access since it is powered with either a UniFi PoE++ Switch, PoE adapter, or even a Universal Power Supply (UPS).

Plus, you can manually configure locks to be fail-safe or fail-secure, so they can be locked or unlocked during a power outage.

Does UniFi Access support key fobs?
UniFi Access supports third-party key fobs that support the 13.56Mhz NFC standard.
